Static and Dynamic Analysis of Bar Structures Using VPL on the Example of Steel Dome
Data
2021
Autorzy
Tytuł czasopisma
ISSN czasopisma
Tytuł tomu
Wydawca
Wydawnictwo Politechniki Łódzkiej
Lodz University of Technology Press
Lodz University of Technology Press
Abstrakt
In this note, the optimization analysis of a steel spatial structure was carried out. The object
considered in the work is a steel mesh dome characterized by a triangular division, which was defined on the
basis of the procedure proposed by Richard Fuller. The optimization analysis was performed using the
Dynamo Studio software – definition of geometric models of domes and dynamic analysis, and also Robot
Structural Analysis Professional – generation of calculation models of the structure. Finally, the most optimal
variants of the mesh dome geometry were selected from the considered ones.
Opis
Słowa kluczowe
parametric design, optimization, dynamo studio, free vibrations, projektowanie parametryczne, optymalizacja, drgania swobodne, oprogramowanie Dynamo Studio
Cytowanie
Redzynia M., Kubacka E., Wirowski A., Static and Dynamic Analysis of Bar Structures Using VPL on the Example of Steel Dome. W: XXVII LSCE 2021 : Lightweight Structures in Civil Engineering. Contemporary problems. Book of Abstracts, Szafran J. (Ed.), Kamiński M. (Ed.), Wydawnictwo Politechniki Łódzkiej, Łódź 2021, s. 105-108, ISBN 978-83-66741-15-7.
