Wpływ doboru warstw na stateczność i nośność ortotropowych płyt pięciowarstwowych
Data
2003
Autorzy
Tytuł czasopisma
ISSN czasopisma
Tytuł tomu
Wydawca
Katedra Wytrzymałości Materiałów i Konstrukcji, Politechnika Łódzka
Department of Strength of Materials & Structures, Lodz University of Technology
Department of Strength of Materials & Structures, Lodz University of Technology
Abstrakt
W pracy przedstawiono analizę wpływu parametrów geometrycznych i
materiałowych na masę, stateczność i nośność płyt prostokątnych, zbudowanych
z pięciu warstw o różnej grubości i wykonanych z różnych materiałów. Analiza
nośności prowadzona jest w zakresie sprężysto-plastycznym, w oparciu o
równania Prandtla-Reussa i kryterium plastyczności Tsai-Wu. Wyniki wstępnych
obliczeń przedstawiono na wykresach.
In the paper the analysis of influence of materiał and geometrical parameters of layers on mass, stability and ultimate load of rectangular plates subjected to compression is carried out. The considered plates are built of orthotropic layers symmetrically arranged with respect to the midplane. The principal axes of orthotropy are parallel to the plate edges. The analysis is conducted in the elastic and elasto-plastic range, basing on Tsai-Wu Criterion and Prandtl-Reuss equations. The solution is reached in the analytical-numerical way by an iterative procedure. The results of preliminary calculations are shown in figures.
In the paper the analysis of influence of materiał and geometrical parameters of layers on mass, stability and ultimate load of rectangular plates subjected to compression is carried out. The considered plates are built of orthotropic layers symmetrically arranged with respect to the midplane. The principal axes of orthotropy are parallel to the plate edges. The analysis is conducted in the elastic and elasto-plastic range, basing on Tsai-Wu Criterion and Prandtl-Reuss equations. The solution is reached in the analytical-numerical way by an iterative procedure. The results of preliminary calculations are shown in figures.
Opis
Słowa kluczowe
ortotropowe płyty, płyty pięciowarstwowe, stateczność płyt prostokątnych, wielowarstwowe płyty, orthotropic plates, five-layer plates, stability of rectangular plates, multi-layer plates
Cytowanie
Grądzki R., Kowal-Michalska K., Wpływ doboru warstw na stateczność i nośność ortotropowych płyt pięciowarstwowych. W: X Sympozjum Stateczności Konstrukcji, Zakopane, 8-12 września 2003, Kowal-Michalska K. (red.), Kołakowski Z. (red.), Wydawca Katedra Wytrzymałości Materiałów i Konstrukcji - Politechnika Łódzka, Łódź 2003, s. 157-164, ISBN 83-914019-2-8.
