Bionic hand control using EMG signals

Oglądaj/ Otwórz
Data wydania
2021Autor
Sencerek, Jędrzej
Zagrodny, Bartłomiej
Metadane
Pokaż pełny rekordAbstrakt
Abstract. 3D printed prototype a human hand which is controled by sEMG
signal was created to simulate two types of fingers motions. The first one includes
fingers flexion/extension and the second one is focused on opposing the thumb. These
two types of motions are executed by one pair of biological muscles, by the meaning
of sEMG signals. The recruting electrodes are attached to both biceps brachii. One of
them is responsible for fingers flexion/thumb abduction, and the other is for fingers
extension/thumb adduction. The simultaneous contraction of both muscles couses a
change in the mode of movement ( fingers - thumb). Control is based on the Arduino
microcontroller extended by two EMG Olimex shields and two servos. The main idea
behind this project was to create an easy and cheap alternative to commercial prosthetic
solutions.
